The data points included in the daily log and the corresponding log action are as shown in
the table below. Data points required by the API Chapter 21 standard are marked with an
asterisk (*). For information on a particular data point, consult Daniel MeterLink online help
(see the help topic for any data point in Daniel MeterLink. Click Help|Gas 3410 Series
Registers Reference, select the Index tab, start typing the data point name until the
desired point is highlighted, and then click the Display button.)
Daily log contentTable 6-1:
Data point Content Log action
PosVolFlow* Totalize and
Snapshot
NegVolFlow* Totalize and
Snapshot
PosVolBase Totalize and
Snapshot
NegVolBase Totalize and
Snapshot
FlowTemperature* Flow-Gated
FlowPressure* Flow-Gated
AbsFlowPressure* Flow-Gated
AccumFlowTime* Totalize
AvgSndVel* Flow-Gated
PrevDayMacro1 Macro
bit31-30
bit 29
bits 28-25
bit 24
bit 23
bit 22
bit 21
bit 20
bit 19
bit 18
bits 17-0
(unused)
DI1
(unused)
IsAcgModuleError
DidPowerFail
DidCnfgChksumChg
IsElecTempOutOfRange
EsElecVoltOutOfRange
IsGCAlarmPresent
IsGCCommErr
(unused)
PrevDayMacro2*: Macro
Directory
