Emerson Mentor MP Short Guide

10 Mentor MP Short Form Guide
www.controltechniques.com Issue Number: 5
Table 2-2 480 V current ratings
Table 2-3 575 V current ratings
*For this rating at 575 V, 150 % overload time is 20 s at 40 °C and 30 s at 35 °C.
Model
AC input
current
DC output current Typical motor power
Continuous Continuous
150 %
overload
@ 400
Vdc
@ 500
Vdc
AAAkWhp
MP25A4(R) 22 25 37.5 9 15
MP45A4(R) 40 45 67.5 15 27
MP75A4(R) 67 75 112.5 27 45
MP105A4(R) 94 105 157.5 37.5 60
MP155A4(R) 139 155 232.5 56 90
MP210A4(R) 188 210 315 75 125
MP350A4(R) 295 350 525 125 200
MP420A4(R) 350 420 630 150 250
MP550A4(R) 450 550 825 200 300
MP700A4(R) 585 700 1050 250 400
MP825A4(R) 665 825 1237.5 300 500
MP900A4(R) 725 900 1350 340 550
MP1200A4(R) 1050 1200 1800 450 750
MP1850A4(R) 1570 1850 2775 700 1150
Model
AC input
current
DC output current
Typical motor
power
(With Vdc = 630 V)
Continuous Continuous
150 %
overload
AAAkWhp
MP25A5(R) 22 25 37.5 14 18
MP45A5(R) 40 45 67.5 25 33
MP75A5(R) 67 75 112.5 42 56
MP105A5(R) 94 105 157.5 58 78
MP155A5(R) 139 155 232.5 88 115
MP210A5(R) 188 210 315 120 160
MP350A5(R) 295 350 525 195 260
MP470A5(R) 395 470* 705 265 355
MP700A5(R) 585 700 1050 395 530
MP825A5(R) 665 825* 1237.5 465 620
MP1200A5(R) 1050 1200 1800 680 910
MP1850A5(R) 1570 1850 2775 1045 1400
