7.3 Transferring data
When a code is entered into Pr xx.00 and the drive is subsequently reset, the drive will
carry out the actions listed in Table 7-2.
Table 7-2 Transferring data
Where yyy indicates the data block number 001 to 999, refer to Table 7-1 for restrictions
on data block numbers.
If the read only flag is set then only codes 6yyy or 9777 are effective.
Codes Actions
Pr x.00 = rEAd 1 Transfer SMARTCARD data block 1 to the drive.
Pr x.00 = rEAd 2 Transfer SMARTCARD data block 2 to the drive.
Pr x.00 = rEAd 3 Transfer SMARTCARD data block 3 to the drive.
Pr x.00 = PrOg 1
Transfer drive parameters as difference from default to SMARTCARD
data block number 1.
Pr x.00 = PrOg 2
Transfer drive parameters as difference from default to SMARTCARD
data block number 2.
Pr x.00 = PrOg 3
Transfer drive parameters as difference from default to SMARTCARD
data block number 3.
Pr x.00 = 2001
Transfer drive parameters as difference from defaults to a bootable
SMARTCARD data block with block number 1. This will clear data block
1 on the card if it already exists.
Pr x.00= 3yyy Transfer drive parameters to a SMARTCARD data block number yyy.
Pr x.00 = 4yyy
Transfer drive data as difference from defaults to SMARTCARD data
block number yyy.
Pr x.00= 5yyy Transfer drive user program to SMARTCARD data block number yyy.
Pr x.00 = 6yyy Transfer SMARTCARD data block yyy to the drive.
Pr x.00 = 7yyy Erase SMARTCARD data block yyy.
Pr x.00 = 8yyy Compare drive parameters with data block yyy.
Pr x.00 = 9555 Clear SMARTCARD warning suppression flag.
Pr x.00 = 9666 Set SMARTCARD warning suppression flag.
Pr x.00= 9777 Clear SMARTCARD read-only flag.
Pr x.00 = 9888 Set SMARTCARD read-only flag.
Pr x.00 = 9999 Erase SMARTCARD.
Pr 11.42 (SE09, 0.30) = Read
Transfer SMARTCARD data block 1 to the drive provided it is a
parameter file.
Pr 11.42 (SE09, 0.30) = Prog Transfer drive parameters to a SMARTCARD data block number 1.
Pr 11.42 (SE09, 0.30) = Auto
Transfer drive parameters to a SMARTCARD data block with data block
number 1 provided.
Pr 11.42 (SE09, 0.30) = boot Pr 11.42 (SE09, 0.30) has been changed since power-up.
NOTE
