5.13 Parameter access level and security
The parameter access levels determine whether the user has access to Menu 0 (in sub
block mode) only or to all of the advanced menus (Menus 1 to 23), in addition to Menu 0
(in linear mode).
The user security determines whether the access to the user is read only or read write.
The user security and the parameter access level can operate independently of each
other as shown in Table 5-5 .
Table 5-5 User security and parameter access levels
RW = Read / write access RO = Read only access
The default settings of the drive are parameter access level L1 and User Security Open,
i.e. read / write access to Menu 0 with the advanced menus, not visible
5.13.1 User security
The user security, when set, prevents write access to any of the parameters (other than
Pr
11.44
(
SE14, 0.35
)
Access Level) in any menu.
Figure 5-8 User security open
Parameter
access level
User security Menu 0 status
Advanced
menus status
L1 Open Sub block RW Not visible
L1 Closed Sub block RO Not visible
L2 Open Linear RW RW
L2 Closed Linear RO RO
Pr 0.00
Pr 0.01
Pr 0.02
Pr 0.03
Pr 0.90
Pr 1.00
Pr 1.01
Pr 1.02
Pr 1.03
Pr 1.50
Pr 1.51
............
............
............
............
............
............
............
............
Pr 0.00
Pr 0.01
Pr 0.02
Pr 0.03
Pr 0.89
Pr 0.90
Pr 1.00
Pr 1.01
Pr 1.02
Pr 1.03
Pr 1.50
Pr 1.51
............
............
............
............
............
............
............
............
User security open
- All parameters: Read / Write access
User security closed
- All parameters: Read Only access
(except Pr ( )
11.44 SE14, 0.35
Pr 23.00
Pr 23.01
Pr 23.02
Pr 23.03
Pr 23.10
Pr 23.11
Pr 0.49
