2.6 Items supplied with the drive
The drive is supplied with a printed manual, a SMARTCARD, a safety information
booklet, an accessory kit box including the items shown in Table 2-9, and a CD ROM
containing all related product documentation and software tools.
Table 2-9 Parts supplied with the drive
Description Size 1 Size 2A / 2B Size 2C / 2D
Control connectors
Tacho connector
Relay connectors
UL warning label
UL warning label for
heatsink temperature
Grounding bracket
Terminal cover
grommets
Terminal shrouds
Terminal shroud base
covers
M4 Screws
Mounting feet brackets
CAUTION
Risk of Electric Shock
Power down unit 10minutes
before removing cover
