Mentor MP Short Form Guide 39
Issue Number: 5 www.controltechniques.com
Safety Information Product information
Mechanical
installation
Electrical
installation
Getting started Running the motor
SMARTCARD
operation
Advanced
parameters
Diagnostics UL listing
Table 4-2 Minimum required line inductance for a typical application (50% ripple content)
4.4.1 Auxiliary AC supply and connections
Table 4-3 Terminal functions
Table 4-4 Line to line supply
Each drive has an onboard field controller with the following current ratings.
Drive
rated
current
System voltage
Typical
current rating
Maximum
current rating
400V 480V 575V 690V
A μH μH μH μHA A
25 220 260 320 21 22
45 220 260 320 38 40
75 220 260 320 63 67
105 220 260 320 88 94
155 160 190 230 130 139
210 120 140 170 176 188
350 71 85 110 120 293 295
420 59 71 351 350
470 80 91 393 395
550 45 54 460 450
700 36 43 53 61 586 585
825 45 52 690 665
900 28 33 753 725
1200 21 25 31 36 1004 1050
1850 18 23 29 32 1570 1655
1. The above assumes the supply has 1.5% impedance.
2. Assumes a minimum supply rating of 5 kA and a maximum rating of 60 kA.
NOTE
Terminals Function
E1, E3 Supply for control electronics and field controller.
L11, L12
Field on / off. When L11 and L12 are open the supply is
disconnected to the field regulator so there will be no field
current.
F+, F- Field supply to the motor.
MA1, MA2 Refer to the Mentor MP User Guide
Specification Value
Maximum nominal supply 480 V
To le r a n c e +1 0 %
Minimum nominal supply 208 V
To le r a n c e -10 %
