Emerson PACMotion VFD Series User Manual

12 PACMotion VFD AC Variable Speed Drive User Guide GFK-3111A
Drive Model Numbers – IP66
Mechanical dimensions and mounting information are shown from section Figure 9: IP66 Units Weights and
Dimensions on page 17.
Electrical specications are shown in section Input/Output Power and Current Ratings on page 84.
Table 6: Drive Model Numbers – IP66
200-240V ±10% - 1 Phase Input
Drive Model Number kW HP Output
Current (A) Frame Size
IC-866-0008-2B1-6# 0.75 1 4.3 2
IC866-0015-2B1-6# 1.5 2 7 2
IC866-0022-2B1-6# 2.2 3 10.5 2
200-240V ±10% - 3 Phase Input
Drive Model Number kW HP Output
Current (A) Frame Size
IC866-0008-2A3-6# 0.75 1 4.3 2
IC866-0015-2A3-6# 1.5 2 7 2
IC866-0022-2A3-6# 2.2 3 10.5 2
IC866-0040-2A3-6# 4 5 18 3
380-480V ±10% - 3 Phase Input
Drive Model Number kW HP Output
Current (A) Frame Size
IC866-0008-4A3-6# 0.75 1 2.2 2
IC866-0015-4A3-6# 1.5 2 4.1 2
IC866-0022-4A3-6# 2.2 3 5.8 2
IC866-0040-4A3-6# 4 5 9.5 2
IC866-0055-4A3-6# 5.5 7.5 14 3
IC866-0075-4A3-6# 7.5 10 18 3
500-600V ±10% - 3 Phase Input
Drive Model Number kW HP Output
Current (A) Frame Size
IC866-0008-603-6# 0.75 1 2.1 2
IC866-0015-603-6# 1.5 2 3.1 2
IC866-0022-603-6# 2.2 3 4.1 2
IC866-0040-603-6# 4 5 6.5 2
IC866-0055-603-6# 5.5 7.5 9 2
IC866-0075-603-6# 7.5 10 12 3
IC866-0110-603-6# 11 15 17 3
NOTE
Replace # with:
0 = No Pronet Module included
P = Pronet Module Included

Emerson PACMotion VFD Series Specifications

General

Brand	Emerson
Model	PACMotion VFD Series
Category	DC Drives
Language	English
