Emerson PACMotion VFD Series User Manual

10 PACMotion VFD AC Variable Speed Drive User Guide GFK-3111A
Drive Model Numbers – IP20
Mechanical Dimensions and Mounting information are shown in section Figure 7: IP20 Weights and
Dimensions on page 15.
Electrical Specications are shown in section Input/Output Power and Current Ratings on page 84.
Table 4: Drive Model Numbers – IP20
200-240V ±10% - 1 Phase Input
NOTE
Replace # with:
0 = No Pronet Module included
P = Pronet Module Included
Drive Model Number kW HP Output Current (A) Frame Size
IC866-0008-2B1-2# 0.75 1 4.3 2
IC866-0015-2B1-2# 1.5 2 7 2
IC866-0022-2B1-2# 2.2 3 10.5 2
200-240V ±10% - 3 Phase Input
Drive Model Number kW HP Output Current (A) Frame Size
IC866-0008-2A3-2# 0.75 1 4.3 2
IC866-0015-2A3-2# 1.5 2 7 2
IC866-0022-2A3-2# 2.2 3 10.5 2
IC866-0040-2A3-2# 4 5 18 3
IC866-0055-2A3-2# 5.5 7.5 24 3
IC866-0075-2A3-2# 7.5 10 30 4
IC866-0110-2A3-2# 11 15 46 4
IC866-0150-2A3-2# 15 20 61 5
IC866-0185-2A3-2# 18.5 25 72 5
380-480V ±10% - 3 Phase Input
Drive Model Number kW HP Output Current (A) Frame Size
IC866-0008-4A3-2# 0.75 1 2.2 2
IC866-0015-4A3-2# 1.5 2 4.1 2
IC866-0022-4A3-2# 2.2 3 5.8 2
IC866-0040-4A3-2# 4 5 9.5 2
IC866-0055-4A3-2# 5.5 7.5 14 3
IC866-0075-4A3-2# 7.5 10 18 3
IC866-0110-4A3-2# 11 15 24 3
IC866-0150-4A3-2# 15 20 30 4
IC866-0185-4A3-2# 18.5 25 39 4
IC866-0220-4A3-2# 22 30 46 4
IC866-0300-4A3-2# 30 40 61 5
IC866-0370-4A3-2# 37 50 72 5
IC866-0450-4A3-2# 45 60 90 6A
IC866-0550-4A3-2# 55 75 110 6A
IC866-0750-4A3-2# 75 100 150 6B
IC866-0900-4A3-2# 90 150 180 6B
IC866-2000-4A3-2# 200 300 370 8
IC866-2500-4A3-2# 250 350 450 8
500-600V ±10% - 3 Phase Input
Drive Model Number kW HP Output Current (A) Frame Size
IC866-0008-603-2# 0.75 1 2.1 2
IC866-0015-603-2# 1.5 2 3.1 2
IC866-0022-603-2# 2.2 3 4.1 2
IC866-0040-603-2# 4 5 6.5 2
IC866-0055-603-2# 5.5 7.5 9 2
IC866-0075-603-2# 7.5 10 12 3
IC866-0110-603-2# 11 15 17 3
IC866-0150-603-2# 15 20 22 3
IC866-0185-603-2# 18.5 25 28 4
IC866-0220-603-2# 22 30 34 4
IC866-0300-603-2# 30 40 43 4
IC866-0370-603-2# 37 50 54 5
IC866-0450-603-2# 45 60 65 5
