Emerson PACMotion VFD Series User Manual

GFK-3111A PACMotion VFD AC Variable Speed Drive User Guide 11
Drive Model Numbers – IP55
Mechanical dimensions and mounting information are shown from section Figure 8: IP55 Weights and
Dimensions on page 16.
Electrical specications are shown in section Input/Output Power and Current Ratings on page 84.
Table 5: Drive Model Numbers – IP55
200-240V ±10% - 3 Phase Input
Drive Model Number kW HP Output Current (A) Frame Size
IC866-0055-2A3-5# 5.5 7.5 24 4
IC866-0075-2A3-5# 7.5 10 30 4
IC866-0110-2A3-5# 11 15 46 4
IC866-0150-2A3-5# 15 20 61 5
IC866-0185-2A3-5# 18.5 25 72 5
IC866-0220-2A3-5# 22 30 90 6
IC866-0300-2A3-5# 30 40 110 6
IC866-0370-2A3-5# 37 50 150 6
IC866-0450-2A3-5# 45 60 180 6
IC866-0550-2A3-5# 55 75 202 7
IC866-0750-2A3-5# 75 100 248 7
380-480V ±10% - 3 Phase Input
Drive Model Number kW HP Output Current (A) Frame Size
IC866-0110-4A3-5# 11 15 24 4
IC866-0150-4A3-5# 15 20 30 4
IC866-0185-4A3-5# 18.5 25 39 4
IC866-0220-4A3-5# 22 30 46 4
IC866-0300-4A3-5# 30 40 61 5
IC866-0370-4A3-5# 37 50 72 5
IC866-0450-4A3-5# 45 60 90 6
IC866-0550-4A3-5# 55 75 110 6
IC866-0750-4A3-5# 75 100 150 6
IC866-0900-4A3-5# 90 150 180 6
IC866-1100-4A3-5# 110 175 202 7
IC866-1320-4A3-5# 132 200 240 7
IC866-1600-4A3-5# 160 250 302 7
500-600V ±10% - 3 Phase Input
Drive Model Number kW HP Output Current (A) Frame Size
IC866-0150-603-5# 15 20 22 4
IC866-0185-603-5# 18.5 25 28 4
IC866-0220-603-5# 22 30 34 4
IC866-0300-603-5# 30 40 43 4
IC866-0370-603-5# 37 50 54 5
IC866-0450-603-5# 45 60 65 5
IC866-0550-603-5# 55 75 78 6
IC866-0750-603-5# 75 100 105 6
IC866-0900-603-5# 90 125 130 6
IC866-1100-603-5# 110 150 150 6
NOTE
Replace # with:
0 = No Pronet Module included
P = Pronet Module Included

Emerson PACMotion VFD Series Specifications

General

Brand	Emerson
Model	PACMotion VFD Series
Category	DC Drives
Language	English
