GFK-3111A PACMotion VFD AC Variable Speed Drive User Guide 71
Advanced Parameters
For Advanced Parameters, basic information only is provided in this guide. The parameter functions are
described more fully in Emerson PACMotion VFD Studio PC software.
Table 40: Parameter Group 6 – Advanced Conguration
Par. Function Setting Range Default Notes
P6-01 Firmware upgrade 0 Disabled 0 This parameter should
not be adjusted by the
user.
1 Update I/O & P/S
2 Update I/O
3 Update P/S
P6-02 Thermal overload management 4 – 32 kHz (Model
Dependent)
4 kHz Minimum Effective
Switching Frequency.
P6-03 Auto reset time delay 1 – 60 Seconds 20 s
P6-04 Relay output hysteresis 0.0 – 25.0% 0.3%
P6-05 Encoder feedback 0 Disabled 0
1 Enabled
P6-06 Encoder PPR 0 - 65535 0
P6-07 Speed error trip threshold 0.0 – 100.0% 5.0%
P6-08 Maximum pulse input frequency 0 – 20 kHz 0 kHz
P6-09 Speed droop 0.0 – 25.0% 0.0%
P6-10 Function Block program 0 Disabled 0
1 Enabled
P6-11 Speed hold time on enable 0 – 250 s 0 s
P6-12
Speed hold / DC inj. time on stop 0 – 250 s 0 s
P6-13 Hoist brake release time 0.0 – 5.0 s 0.2 s
P6-14 Hoist brake apply time 0.0 – 5.0 s 0.3 s
P6-15 Hoist brake pre-torque level 0.0 – 200.0% 8.0%
P6-16 Hoist brake pre-torque time limit 0.0 – 25.0 s 5.0 s
P6-17 Maximum torque limit time 0.0 – 25.0 s 0.0 s
P6-18 DC injection current 0.0 – 100.0% 0.0% This function is
active only for
Induction Motors
(IM) and Synchronous
Reluctance Motor
(SyncRM).
P6-19 Brake resistor resistance Model Dependent
P6-20 Brake resistor power Model Dependent
P6-21 Brake chopper under temp. duty 0.0 – 20.0% 2.0%
P6-22 Cooling fan run time reset 0 No Reset 0
1 Reset
P6-23 Energy meters reset 0 No Reset 0
1 Reset
P6-24 Maintenance time interval 0 – 60000 Hours 0 Hours
P6-25 Reset maintenance indicator 0 No Reset 0
1 Reset
P6-26 Analog output AO1 scaling 0.0 – 500.0% 100.0%
P6-27 Analog output AO1 offset -500.0 – 500.0% 0.0%
P6-28 P0-80 index select 0 – 200 0
P6-29 User default parameters 0 No Function 0
1 Save user parameters
2 Clear user parameters
P6-30 Advance access code 0 – 9999 201
