Product Rating Label Location
All PACMotion VFD models carry a rating label, which can be located as follows:
Figure 2: IP20 Models Figure 3: IP55 Models Figure 4: IP66 Models
On right hand side when viewed
from the front.
On right hand side when viewed
from the front.
On the top surface.
Understanding the Rating Label
The product rating label provides the following information.
Figure 5: Understanding the Rating Label
Key
Output
SERIAL:
Assembled in the UK
CAUTION
IC866-0008-4A3-20
023042
11111111111
HP
ODP-2-24010-3HF42-MN
11111111111
24/03/2020
PACMotion VFD
Flash
Test
380-480
V +/-10%
023042
ODP-2 IP20, S2, 380-480V,
3Ph, 1HP, 2.2A, Brk
SW 2.50
Read User Guide Before
installation
Power down for
5min before
Risk of Electric Shock
or servicing
removing
cover
to User Guide
2 0I P
SCCR: For rating and
Listed2AD0
E181349
Ind.Cont.Eq.
Input 380-480 3
2.4
0-500 2.2
1
3
0-500
50/60
0.8
HPØ F(Hz) I (A) kW
V
and protection refer
Intelligent Platforms, LLC
2500 Austin Drive
Charlottesville, VA 22911
NEM A 12
Customer Tag #
1.0 HPVariable Frequency Drive
SN
PN
IC866-0008-4A3-20-XY
1 Model Code
2 Enclosure Type and IP Rating
3 Firmware Version
4 Serial Number
5 Technical Data – Supply Voltage
6
Technical Data – Maximum
continuous output current
7 Part Code
1
3
4
5
7
2
6
