8 PACMotion VFD AC Variable Speed Drive User Guide GFK-3111A
General Information and Ratings
Identifying the Drive by Model Number
The model number of each PACMotion VFD is constructed according to the following system:
Figure 1: Identifying the Drive by Model Number
IC866 - 0015 - 4 B 1 - 2 P -
XY
Product name:
PACMotion VFD
Catalog Sufx:
X = Current HW Revision
Y = Current FW Revision
Recommended motor power:
0015 = 1.5 kW
Option card:
P = Pronet RT (Standard)
0 = Empty (Purchase separately)
Connection voltage:
2 = 200 – 240 V
4 = 380 – 480 V
6 = 500 – 600 V
Design:
2 = Standard IP20 housing
5 = IP55/NEMA-12K housing
6 = IP66/NEMA-4X housing
Interference suppression on the input:
0 = None
A = Class C2
B = Class C1
Connection type:
1 = 1-phase
3 = 3-phase
(60Hz) = Country specic variant: 60 Hz design
