Figure 3-2 Installation of an SI option module on Unidrive M200 to M400 (sizes
5 to 8)
• Place the option module onto the drive as shown in (2) until the module clicks into
place. The terminal cover on the drive holds the option module in place, so this must
now be replaced.
1
2
