11.2.1 Module error codes
If the SI-PROFIBUS detects an error during operation it will force a drive trip. Table 11.2
shows all the possible SI-PROFIBUS error codes.
Table 11.2 SI-PROFIBUS error codes
11.2.2 PROFIBUS error code
If the SI-PROFIBUS module detects a PROFIBUS error during operation it will force a
drive trip. Table 11.3 shows the possible SI-PROFIBUS error codes.
Table 11.3 SI-PROFIBUS error codes
Value Text Description
200 No trip No trip
201 SW fault Software fault
202 BG overrun Background task overrun
203 FW invalid Invalid firmware
204 Drv unknown Unknown drive type
205 Drv unsupported Unsupported drive type
206 Mode unknown Unknown mode
207 Mode unsupported Unsupported mode
208 FLASH corrupt Corrupted NV Flash
209 Dbase init Database initialization error
210 FS init File system initialization error
211 Memory alloc Memory allocation error
212 Filesystem File system error
213 Save configuration Error while saving configuration file
214 Load configuration Error while loading
215 Oht Overheated configuration file
216 TO drv Watchdog timeout
217 eCMP eCMP comms failure
218 TO eCMP slot 1 Slot 1 eCMP timeout
219 TO eCMP slot 2 Slot 2 eCMP timeout
220 TO eCMP slot 3 Slot 3 eCMP timeout
221 TO eCMP slot 4 Slot 4 eCMP timeout
Value Text Description
100 No trip No trip
101 Link loss Network link lost
102 Invalid data Invalid Fieldbus specific data
103 VPC3 stack VPC3 stack error
