Internet Printer Connection and HP Web JetAdmin
2. Select Settings, and then select “Printers” option.
3. Click Add Printer icon. Appear welcome to the add
printer wizard, Click Next.
4. Select Network printer option, and then click “Next”.
5. Select Connect to a printer on the Internet or on your
intranet option, appear as follow picture.
6. In URL’s box, input print server’s IP address, for
example, http://192.168.10.182/lp1. Then Click Next.
** One port should be the port name as lp1.
** Three ports should be the port name as lp1, lp2, and
lp3.
7. It will check print server to connect to HP printer, if not, it
4 - 2
