Cerabar M, Deltabar M, Deltapilot M Commissioning with an operating menu (onsite display/FieldCare)
Endress+Hauser 109
... Setup ... Extended setup ... Level
(Level measuring mode)
Full pressure (032)
Full pressure (187)
 ä 124
Full height (033)
Full height (188)
 ä 124
Adjust density (034)  ä 125
Process density (035)  ä 125
Level before lin. (019)  ä 125
Linearization Lin. mode (037)  ä 125
Unit after lin. (038)  ä 126
Line numb. (039)  ä 126
X-value (040) (manual entry)
X-value (123) (in linear/activ
table)
 ä 126
Y-value (041) (manual entry/in
semi-auto. entry)
Y-value (194) (in linear/activ table)
 ä 126
Edit table (042)  ä 126
Tank description (173)  ä 126
Tank content (043)  ä 126
Flow ("Flow" measuring mode)
(Deltabar M)
Flow type (044)  ä 127
Mass flow unit (045)  ä 127
Norm. flow unit (046)  ä 127
Std. flow unit (047)  ä 127
Flow unit (048)  ä 128
Max. flow (009)  ä 128
Max. pressure flow (010)  ä 128
Set low-flow cut-off (049)  ä 128
Flow (018)  ä 128
Analog Input 1 Channel/CHANNEL (171)  ä
130
Out value (195)  ä 130
Out status (196)  ä 130
Analog Input 2 Channel/CHANNEL (200)  ä 130
Out value (201)  ä 130
Out status (202)  ä 130
Analog Input 3
(if instantiated)
Channel/CHANNEL (238)  ä 130
Out value (239)  ä 130
Out status (240)  ä 130
Analog Input 4
(if instantiated)
Channel/CHANNEL (241)  ä 130
Out value (242)  ä 130
Out status (243)  ä 130
Analog Input 5 (Deltabar M)
(if instantiated)
Channel/CHANNEL (255)  ä 130
Out value (256)  ä 130
Out status (257)  ä 130
Totalizer 1 (Deltabar M) Eng. unit totalizer 1 (058) (059)
(060) (061)
 ä 132
Totalizer 1 mode (175)  ä 132
Level 1 Level 2 Level 3 Level 4 Page
