Cerabar M, Deltabar M, Deltapilot M Operation
Endress+Hauser 65
6.4.8 Index tables of Endress+Hauser parameters
The following tables list the manufacturer-specific device parameters for the Resource Block,
the Transducer Blocks and the Analog Input Blocks. For the FF parameters, see either the
FF specification or descriptions from Page 138 ff.
General explanatory remarks
Data type
• DS: data structure, contains data types such as unsigned8, Octet String etc.
• Float: IEEE 754 format
• Visible String: ASCII coded
• Unsigned:
– Unsigned8: value range = 0 to 255
– Unsigned16: value range = 0 to 65535
– Unsigned32: value range = 0 to 4294967295
Storage Class
• Cst: constant parameter
• D: dynamic parameter
• N: nonvolatile parameter
•S: static parameter
If this is a write parameter, the MODE_BLK column indicates the block mode in which the
parameter can be written. Some parameters can only be written in the OOS block mode.
The "Reset codes" column indicates which reset codes reset the parameter.
Resource Block
Parameter name, "Label parameter" option and
display in FieldCare / parameter name in
accordance with DD
Index Data type Size
(Byte)
Storage
Class
Read Write MODE_BLK Reset
codes
Page
Device dialog/DEVICE_DIALOG 42 Unsigned8 1 D x  ä 172
Operator code/S_W_LOCK 43 Unsigned16 2 S x x wr for Auto, OOS 7864, 333  ä 172
Lockstate/STATUS_LOCKING 44 Unsigned8 1 D x  ä 172
DIP switch/SWITCH_STATUS_LIST 45 Unsigned8 1 S x  ä 172
Electr. serial no./ ELECTRONIC_SERIAL _NUMBER 46 Visible
String
16 S x  ä 173
Sci octet str/SCI_OCTET_STRING 47 Visible
String
40 D x x wr for Auto, OOS  ä 173
Download select./DOWNLOAD_OVERWRITE_SELECTION 48 Unsigned8 1 D x x wr for Auto, OOS  ä 173
Code definition/USER_S_W_UNLOCK 49 Unsigned16 1 S x x wr for Auto, OOS  ä 173
Capability level/CAPABILITY_LEVEL 50 Unsigned8 1 D x  ä 173
Compat. level/COMPATIBILITY_LEVEL 51 Unsigned8 1 S x  ä 174
ENP version/FF_E_N_P_VERSION 52 Visible
String
32 S x x  ä 174
Pd-tag/FF_PD_TAG 53 Visible
String
32 D x x wr for Auto, OOS  ä 174
Serial number/DEVICE_SERIAL_NUMBER 54 Visible
String
16 S x wr for Auto, OOS  ä 174
Order code part 1/E_N_P_ORDER_CODE_1 55 Visible
String
32 S x wr for Auto, OOS  ä 174
Order code part 2/E_N_P_ORDER_CODE_2 56 Visible
String
32 S x wr for Auto, OOS  ä 174
Order code/DEVICE_ORDER_IDENT 57 Visible
String
32 S x wr for Auto, OOS  ä 174
Firmware version/FF_SOFTWARE_REVISION 58 Visible
String
32 S x  ä 174
Hardware rev./FF_HARDWARE_VERSION 59 Visible
String
16 S x  ä 175
FF com stack ver/FF_COM_VERSION 60 Visible
String
16 S x  ä 175
MS res directory/MS_RES_ DIRECTORY 61 Unsigned8 10 S x 
ä 175
