Operation Cerabar M, Deltabar M, Deltapilot M
66 Endress+Hauser
Pressure Transducer Block
Parameter name, "Label parameter" option and
display in FieldCare / parameter name in
accordance with DD
Index Data type Size
(Byte)
Storage
Class
Read Write MODE_BLK Reset
codes
Page
Device dialog/DEVICE_DIALOG 31 Unsigned8 1 D x ä 182
Operator code/S_W_LOCK 32 Unsigned16 2 S x x wr for Auto, OOS 7864, 333 ä 182
Lockstate/STATUS_LOCKING 33 Unsigned8 1 D x ä 182
DIP switch/SWITCH_STATUS_LIST 34 Unsigned8 1 D x ä 183
Scale In/SCALE_IN 35 DS-68 11 S x x OOS 7864, 333 ä 183
Scale Out/SCALE_OUT 36 DS-68 11 S x x OOS 7864, 333 ä 183
Damping/PRESSURE_1_DAMPING 37 Float 4 S x x OOS 7864, 333 ä 184
Pos. zero adjust/PRESSURE_1_ACCEPT_ZERO_INSTALL 38 Unsigned8 1 D x x OOS ä 184
Calib. offset/PRESSURE_1_INSTALL_OFFSET 39 Float 4 S x x OOS 7864, 333,
2509
ä 184
Lo trim measured/PRESSURE_1_LOWER_CAL_MEASURED 40 Float 4 S x 2509 ä 184
Hi trim measured/PRESSURE_1_UPPER_CAL_MEASURED 41 Float 4 S x 2509 ä 184
Measuring mode/OPERATING_MODE 42 Unsigned8 1 S x x OOS 7864 ä 185
Level selection/LEVEL_ADJUSTMENT 43 Unsigned8 1 S x x OOS 7864,333 ä 185
Corrected press./PRESSURE_1_AFTER_CALIBRATION 44 Float 4 D x ä 185
Meas. pressure/PRESSURE_1_FINAL_VALUE 45 Float 4 D x ä 185
Lin. mode/LINEARIZATION_ TABLE_MODE 46 Unsigned8 1 S x x OOS 7864 ä 187
Unit after lin./AFTER_LINEARIZATION_UNIT 47 Unsigned16 1 S x x OOS ä 187
Line numb./LINEARIZATION_ TABLE_INDEX 48 Unsigned8 1 D x x ä 187
X-value:/TB_LINEARIZATION_ TABLE_X_VALUE 49 Float 4 S x x OOS 7864, 333 ä 187
Y-value:/TB_LINEARIZATION_ TABLE_Y_VALUE 50 Float 4 S x x OOS 7864, 333 ä 187
Edit table/LINEARIZATION_TABLE_EDIT 51 Unsigned8 1 D x x OOS ä 188
Tank Description/LEVEL_TANK_ DESCRIPTION 52 Visible
String
32 S x x wr for Auto, OOS 7864 ä 188
Tank content/MEASURED_TANK_CONTENT_AFTER_SIM 53 Float 4 D x ä 188
Sensor pressure/PRESSURE_1_AFTER_SENSOR 54 Float 4 D x
ä 188
Pressure af. damp./ PRESSURE_1_AFTER_DAMPING 55 Float 4 D x ä 188
Level before lin/MEASURED_LEVEL_AFTER_SIMULATION 56 Float 4 D x ä 189
Lin tab index 01/LIN_TAB_X_Y_VALUE_1 57 Record 8 S x x OOS 7864 ä 190
... ... Record 8 S x x OOS 7864 ...
Lin tab index 32/LIN_TAB_X_Y_VALUE_32 88 Record 8 S x x OOS 7864 ä 190
Sensor meas. type/SENSOR_MEASUREMENT_TYPE 89 Unsigned16 2 D x ä 190
Height unit/HEIGHT_UNIT_EASY 90 Unsigned16 2 S x x OOS ä 190
Unit before Lin./OUT_UNIT_EASY 91 Unsigned16 2 S x x OOS ä 191
Calibration mode/LEVEL_ADJUST_MODE_EASY 92 Unsigned8 1 S x x OOS ä 191
Density unit/DENSITY_UNIT_EASY 93 Unsigned16 2 D x ä 191
Adjust density/LEVEL_ADJUST_DENSITY_EASY 94 Float 4 S x x OOS 7864, 333 ä 191
Empty height/ LEVEL_OFFSET_EASY 95 Float 4 S x x OOS 7864, 333 ä 192
Full height/LEVEL_100_PERCENT_EASY 96 Float 4 S x x OOS 7864, 333 ä 192
Process density/LEVEL_MEASUREMENT_DENSITY_EASY 97 Float 4 S x x OOS 7864, 333 ä 192
Meas. level/MEASURED_ACTUAL_LEVEL_EASY 98 Float 4 D x ä 192
Full calib./HIGH_LEVEL_EASY 99 Float 4 S x x OOS 7864, 333 ä 192
Empty calibration/LOW_LEVEL_EASY 100 Float 4 S x x OOS 7864, 333 ä 193
Full pressure/HIGH_LEVEL_PRESSURE_EASY 101 Float 4 S x x OOS 7864, 333 ä 193
Empty pressure/LOW_LEVEL_PRESSURE_EASY 102 Float 4 S x x OOS 7864, 333 ä 193
Electr. delta P/ELECTRIC_DELTA_P_CONTROL 103 Unsigned8 1 S x x OOS ä 193
E.delta p selec./E_DELTA_P_INPUT_SELECTOR 104 Unsigned8 1 S x x OOS ä 193
E. delta p value/E_DELTA_P_VALUE 105 Float 4 D x ä 193
E. delta p status/E_DELTA_P_STATUS 106 Unsigned8 1 D x ä 194
E.delta p unit/E_DELTA_P_INPUT_UNIT 107 Unsigned16 2 S x x OOS ä 194
Fixed ext. value/ELECTRIC_DELTA_P_CONSTANT 108 Float 4 S x x OOS
ä 194
Min. meas. press./PRESSURE_1_MIN_RESETABLE 109 Float 4 D x ä 194
Max. meas. press./PRESSURE_1_MAX_RESETABLE 110 Float 4 D x ä 194
Reset peakhold/RESET_TRANSMITTER_OBSERVATION 111 Unsigned8 1 D x x OOS ä 194
Sensor temp. (Cerabar/Deltapilot)/
MEASURED_TEMPERATURE_1
112 Float 4 D x ä 194
Temp. eng. unit/TEMPERATURE_UNIT 113 Unsigned16 2 S x x OOS ä 195
Device name str./GENERIC_DEVICE_TYPE 114 Unsigned8 1 S x ä 195
Format 1st value/DISPLAY_MAINLINE_FORMAT 115 Unsigned8 1 S x ä 195
