Endress+Hauser Cerabar M - Page 67

Cerabar M, Deltabar M, Deltapilot M Operation
Endress+Hauser 67
DP_FLOW Block (Deltabar M)
Display Transducer Block
Parameter name, "Label parameter" option and
display in FieldCare / parameter name in
accordance with DD
Index Data type Size
(Byte)
Storage
Class
Read Write BLK_MODE Reset
codes
Page
Device dialog/DEVICE_DIALOG 11 Unsigned8 1 D x  ä 195
Operator code/S_W_LOCK 12 Unsigned16 2 S x x wr for Auto, OOS 7864 , 333  ä 195
Lockstate/STATUS_LOCKING 13 Unsigned8 1 D x  ä 195
DIP switch/SWITCH_STATUS_LIST 14 Unsigned8 1 D x  ä 196
Flow meas. type/FLOW_TYPE 15 Unsigned8 1 S x x OOS  ä 196
Flow/FLOW_AFTER_SUPPRESSION 16 Float 4 D x  ä 196
Flow unit/FLOW_UNIT 17 Unsigned16 2 S x x OOS 7864 , 333  ä 197
Set. L. Fl. Cut-off/CREEP_FLOW_SUPRESSION_OFF_THRES 18 Float 4 S x x OOS 7864 , 333  ä 198
Flow Max/MAX_FLOW 19 Float 4 S x x OOS  ä 198
Pressure af. damp./ PRESSURE_1_AFTER_DAMPING 20 Float 4 D x  ä 198
Max press. flow/FLOW_MAX_PRESSURE 21 Float 4 S x x OOS 7864 , 333  ä 199
Press. eng. unit/PRESSURE_1_UNIT 22 Unsigned16 2 S x x OOS  ä 199
Totalizer 1/TOTALIZER_1 23 DS-65 5 D x  ä 199
Eng. unit total. 1/TOTALIZER_1_UNIT 24 Unsigned16 2 S x x OOS 7864 , 333  ä 199
Totalizer 1 mode/TOTALIZER_1_MODE 25 Unsigned8 1 S x x OOS  ä 199
Total. 1 failsafe/TOTALIZER_1_FAIL_ SAFE_MODE 26 Unsigned8 1 S x x OOS  ä 199
Reset Totalizer 1/TOTALIZER_1_RESET 27 Unsigned8 1 D x x OOS  ä 200
Totalizer 1/TOTALIZER_1_STRING_VALUE 28 Visible
String
8D x  ä 200
Totalizer 1 overflow/TOTALIZER_1_STRING_OVERFLOW 29 Visible
String
8D x  ä 200
Totalizer 2/TOTALIZER_2 30 DS-65 5 D x  ä 200
Eng. unit total. 2/TOTALIZER_2_UNIT 31 Unsigned16 2 S x x OOS 7864 , 333  ä 200
Totalizer 2 mode/TOTALIZER_2_MODE 32 Unsigned8 1 S x x OOS 7864 , 333  ä 200
Total. 2 failsafe/TOTALIZER_2_FAIL_SAFE_MODE 33 Unsigned8 1 S x x OOS  ä 200
Totalizer 2/TOTALIZER_2_STRING_VALUE 34 Visible
String
8D x  ä 201
Total. 2 overflow/TOTALIZER_2_STRING_OVERFLOW 35 Visible
String
8D x  ä 201
Measuring mode/OPERATING_MODE 36 Unsigned8 1 D x  ä 201
High-press. side/PRESSURE_1_INPUT_INV 37 Unsigned8 1 D x x OOS 7864  ä 201
Device name str./GENERIC_DEVICE_TYPE 38 Unsigned8 1 S x  ä 201
Format 1st value/DISPLAY_MAINLINE_FORMAT 39 Unsigned8 1 S x  ä 201
Parameter name, "Label parameter" option and
display in FieldCare / parameter name in
accordance with DD
Index Data type Size
(Byte)
Storage
Class
Read Write BLK_MODE Reset codes Page
Device dialog/DEVICE DIALOG 10 Unsigned8 1 D x  ä 202
Operator code/S_W_LOCK 11 Unsigned16 2 S x x wr for Auto, OOS 7864, 333  ä 202
Lockstate/STATUS_LOCKING 12 Unsigned8 1 D x  ä 202
Format 1st value/AUTOMATIC_MAIN_LINE_FORMAT 13 Unsigned8 1 S x x wr for Auto, OOS 7864  ä 202
Language/DISPLAY_LANGUAGE 14 Unsigned8 1 S x x wr for Auto, OOS 7864  ä 202
Display mode/DISPLAY_MAIN_LINE_1_CONTENT 15 Unsigned8 1 S x x wr for Auto, OOS  ä 202
Add. disp. value/DISPLAY_MAINLINE_2_CONTENT 16 Unsigned8 1 S x x wr for Auto, OOS  ä 203
FF input source/DISPLAY_INPUT_SELECTOR 17 Unsigned8 1 S x x wr for Auto, OOS  ä 203
FF input unit/DISPLAY_INPUT_UNIT 18 Unsigned16 1 S x x wr for Auto, OOS  ä 203
FF input form./DISPLAY_INPUT_FORMAT 19 Unsigned8 1 S x x wr for Auto, OOS  ä 203
Device name str./GENERIC_DEVICE_TYPE 20 Unsigned8 1 S x  ä 203
Measuring mode/OPERATING_MODE 21 Unsigned8 1 D x  ä 204
