Operation Cerabar M, Deltabar M, Deltapilot M
68 Endress+Hauser
Diagnostic Transducer Block
Analog Input Blocks
6.4.9 Methods
The FOUNDATION Fieldbus Specification includes the use of methods to make device
operation easier. A method is a sequence of interactive steps to be carried out in the specified
order so as to configure certain device functions.
The following methods are available for the devices:
• Device info, locking/unlocking, ENP parameters, restart (Resource Block)
• Setup, level, linearization, peak hold indicator, sensor data, sensor trim (TRD Block)
• Flow, totalizer (DP_FLOW Block = Deltabar M)
• Diagnostics, simulation, reset (Diagnostic Block)
• Display/operation (Display Block)
For further information on accessing methods, see the description of the FF configuration
program used.
Parameter name, "Label parameter" option and
display in FieldCare / parameter name in
accordance with DD
Index Data type Size
(Byte)
Storage
Class
Read Write BLK_MODE Reset
codes
Page
Device dialog/DEVICE DIALOG 10 Unsigned8 1 D x  ä 204
Operator code/S_W_LOCK 11 Unsigned16 2 S x x wr for Auto, OOS 7864, 333  ä 204
Lockstate/STATUS_LOCKING 12 Unsigned8 1 D x  ä 204
DIP switch/SWITCH_STATUS_LIST 13 Unsigned8 1 D x  ä 204
Simulation mode/SIMULATION_MODE 14 Unsigned8 1 D x x OOS  ä 205
Simulation unit/SIMULATION_UNIT 15 Unsigned8 1 D x x 7864  ä 206
Simulated Value/SIMULATED_VALUE 16 Float 4 D x x OOS  ä 206
Sim. error no./ALARM_SIMULATION_VALUE 17 Unsigned16 2 D x x OOS  ä 206
Status/DEVICE_STATUS 18 Unsigned8 1 D x  ä 206
Diagnostic code/ACTUAL_HIGHEST_ALARM 19 Unsigned16 2 D x  ä 206
Instructions/ACTUAL_MAINTENANCE_INSTRUCT 20 Unsigned16 2 D x  ä 206
Last diag. code/LAST_ALARM_INFO_IO 21 Unsigned16 2 D x  ä 206
Reset logbook/RESET_ALARM_HISTORY 22 Unsigned8 2 D x x wr for Auto, OOS  ä 207
Actual errors/DIAG_ALARM_TABLE 23 OctetString8 8 D x  ä 207
Operating hours/OPERATING_HOURS_VALUE 24 Unsigned32 4 S x  ä 207
Diagnostic code/ACTUAL_HIGHEST_ALARM 25 Record 20 D x  ä 207
Instructions/ACTUAL_MAINTENANCE_INSTRUCT_INFO 26 Record 20 D x  ä 207
Last diag. code/LAST_ALARM_INFOS 27 Record 20 D x  ä 207
Reset/RESET_INPUT_VALUE 28 Unsigned16 2 D x x wr for Auto, OOS  ä 207
Config. Recorder/CONFIGURATION_ COUNTER 29 Unsigned16 2 S x  ä 207
Alarm behav. P/UNDER_OVER_PRESSURE_BEHAVIOR 30 Unsigned8 1 S x x OOS  ä 208
Parameter name, "Label parameter" option and
display in FieldCare / parameter name in
accordance with DD
Index Data type Size
(Byte)
Storage
Class
Read Write BLK_MODE Reset
codes
Page
Fsafe type/FSAFE_TYPE
FieldCare= not supported.
37 Unsigned8 1 S x x OOS, MAN  ä 217
Fsafe value/FSAFE_VALUE
FieldCare= not supported.
38 Float 4 S x x wr for Auto,
OOS, MAN
 ä 217
High High Alarm Output Discrete/HIHI_ALM_OUT_D
FieldCare= not supported.
39 DS66 2 D x x wr for Auto,
OOS, MAN
 ä 217
High alarm output discrete/HI_ALM_OUT_D
FieldCare= not supported.
40 DS66 2 D x x wr for Auto,
OOS, MAN
 ä 217
Low alarm output discrete/LO_ALM_OUT_D
FieldCare= not supported.
41 DS66 2 D x x wr for Auto,
OOS, MAN
 ä 217
Low Low Alarm Output Discrete/LOLO_ALM_ OUT_D
FieldCare= not supported.
42 DS66 2 D x x wr for Auto,
OOS, MAN
 ä 217
Select Alarm Mode/ALARM_MODE
FieldCare= not supported.
43 Unsigned8 1 S x x wr for Auto,
OOS, MAN
 ä 218
Alarm Output Discrete/ALM_OUT_D
FieldCare= not supported.
44 DS66 2 D x x wr for Auto,
OOS, MAN
 ä 218
Block Error Description/BLOCK_ERR_DESC_1
FieldCare= not supported.
45 Unsigned32 4 D x wr for Auto,
OOS, MAN
 ä 218
