System integration Cerabar PMP21 IO-Link
22 Endress+Hauser
8.2.1 Endress+Hauser-specific device data
ISDU (dec) Descriptio
n
ISDU
(hex)
Size
(byte)
Data type Access Default
value
Value
range
Offset/
gradient
Data
storage
Range
limits
66 Sim.
current
0x0042 1 UintegerT r/w 0 ~ off
3 ~ 3.5
mA
4 ~ 4 mA
5 ~ 8 mA
6 ~ 12 mA
7 ~16 mA
8 ~ 20 mA
9 ~ 21.95
mA
No
67 Unit
changeove
r
0x0043 1 UintegerT r/w 0 = bar 0 ~ bar
1 ~ kPa
2 ~ psi
3 ~ MPa
Yes
68 Zero point
configurat
ion (ZRO)
0x0044 4 IntegerT r/w 0 as 00.00%
Default
0.00%
Yes
69 Zero point
adoption
(GTZ)
0x0045 1 UintegerT w No
70 Damping
(TAU)
0x0046 2 UintegerT r/w 20 in 000.0
sec
Default
2.0 sec
- Yes 0 - 9999
71 Lower
Range
Value for
4 mA
(STL)
0x0047 4 IntegerT r/w 0 as 00.00%
Default
0.00%
bar:
0/0.001
kPa: 0/0.1
MPa:
0/0.0001
psi:
0/0.01
Yes -
72 Upper
Range
Value for
20 mA
(STU)
0x0048 4 IntegerT r/w 10000 as 00.00%
Default
100.00%
bar:
0/0.001
kPa: 0/0.1
MPa:
0/0.0001
psi:
0/0.01
Yes -
73 Pressure
applied for
4 mA(GTL
)
0x0049 1 UintegerT w - - - No -
74 Pressure
applied for
20 mA
(GTU)
0x004A 1 UintegerT w - - - No -
75 Alarm
current
(FCU)
0x004B 1 Uinteger r/w 1 ~ MAX 0 ~ MIN
1 ~ MAX
2 ~ HOLD
- Yes -
82 Hi Max
value
(maximu
m
indicator)
0x0052 4 IntegerT r 0 - - No -
83 Lo Min
value
(minimum
indicator)
0x0053 4 IntegerT r 0 - - No -
