Cerabar PMP21 IO-Link System integration
Endress+Hauser 23
ISDU (dec) Descriptio
n
ISDU
(hex)
Size
(byte)
Data type Access Default
value
Value
range
Offset/
gradient
Data
storage
Range
limits
84 Revisionco
unter
(RVC)
0x0054 2 UintegerT r 0 - - No -
85 Simulation
Switch
Output
(OU1)
0x0055 1 UintegerT r/w 0 = OFF 0 ~ OFF
1 ~ OU1 =
low (OPN)
2 ~ OU1 =
high (CLS)
- No -
88 FUNC 0x0058 1 UintegerT r/w 1 =
4 to 20 m
A(I)
0 ~ OFF
1 ~
4 to 20 m
A
- Yes -
256 Device
type
0x0100 2 UintegerT r 0x92FD - - No -
257 ENP_VER
SION
0x0101 16 StringT r 02.03.00 - - No -
259 extended
Ordercode
0x0103 60 StringT r - - - No -
8.2.2 IO-Link-specific device data
ISDU (dec) Description ISDU (hex) Size (byte) Data type Access Default value Value range Data storage
7...8 VendorID 0x0007...
0x0008
- - r 17 No
9...11 DeviceID 0x0009...
0x000B
- - r 0x000Fxx - No
16 VendorName 0x0010 max. 64 StringT r Endress+Hauser - No
17 VendorText 0x0011 max. 64 StringT r People for Process
Automation
- No
18 ProductName 0x0012 max. 64 StringT r Cerabar - No
19 ProductID 0x0013 max. 64 StringT r PMx2x - No
20 ProductText 0x0014 max. 64 StringT r Absolute and gauge
pressure
- No
21 Serial number 0x0015 max. 64 StringT r - - No
22 Hardware Revision 0x0016 max. 64 StringT r - - No
23 Firmware Version 0x0017 max. 64 StringT r - - No
24 Application Specific
Tag
0x0018 32 StringT r/w - - Yes
25 Function Tag 0x0019 32 StringT r/w *** - No
26 Location Tag 0x001A 32 StringT r/w *** - No
36 Device status 0x0024 1 Integer T r 0 0 ~ Device is OK
1 ~ Maintenance
required
2 ~ Out of specification
3 ~ Functional check
4 ~ Failure
No
37 Detailed Device Status 0x0025 3 OctetStringT - - No
260 Actual Diagnostic
(STA)
0x0104 4 StringT r 0 - No
261 Last Diagnostic (LST) 0x0105 4 StringT r 0 - No
