System integration Cerabar PMP21 IO-Link
24 Endress+Hauser
Teach - Single value
ISDU (dec) Description ISDU (hex) Size (byte) Data type Access Default value Value range Data storage
58 Teach Select 0x003A 1 UintegerT r/w 1 0 ~ Default Channel = SSC1.1 Pressure
1 ~ SSC1.1 Pressure
2 ~ SSC1.2 success
255 ~ All SSC
No
59 Teach Result State 0x003B 1 UintegerT r 0 0 ~ Idle
1 ~ SP1 success
2 ~ SP2 success
5 ~ Busy
7 ~ Error
No
Switching Signal Channel 1.1 Pressure
ISDU (dec) Subindex Description ISDU (hex) Size (byte) Data type Access Default
value
Value
range
Data
storage
60 24 SSC1.1
Param.SP1
0x003C 4 Float32T r/w 9000.0 - Yes
60 23 SSC1.1
Param.SP2
0x003C 4 Float32T r/w 1000.0 - Yes
61 01 SSC1.1
Config.Logic
0x003D 1 UintegerT r/w 0 0 ~ High
active
1 ~ Low
active
Yes
61 02 SSC1.1
Config.Mod
e
0x003D 1 UintegerT r/w 0 0 ~
Deactivation
1 ~ Single
point
2 ~ Window
3 ~ Two-
point
Yes
61 03 SSC1.1
Config.Hyst
0x003D 4 Float32T r/w 10.0 - Yes
Switching Signal Channel 1.2 Pressure
ISDU (dec) Subindex Description ISDU (hex) Size (byte) Data type Access Default
value
Value
range
Data
storage
60 24 SSC1.2
Param.SP1
0x003C 4 Float32T r/w 9500.0 - Yes
60 23 SSC1.2
Param.SP2
0x003C 4 Float32T r/w 1500.0 - Yes
61 01 SSC1.2
Config.Logic
0x003D 1 UintegerT r/w 0 0 ~ High
active
1 ~ Low
active
Yes
61 02 SSC1.2
Config.Mod
e
0x003D 1 UintegerT r/w 0 0 ~
Deactivation
1 ~ Single
point
2 ~ Window
3 ~ Two-
point
Yes
61 03 SSC1.2
Config.Hyst
0x003D 4 Float32T r/w 10.0 - Yes
