System integration Cerabar PMP21 IO-Link
26 Endress+Hauser
Sp1
H
MV
i
a
A0046577
 2 SSC, Single Point
H Hysteresis
Sp1 Switch point 1
MV Measured value
i inactive (orange)
a active (green)
Window Mode
SP
hi
always corresponds to whichever value is higher, SP1 or SP2, and SP
lo
always
corresponds to whichever value is lower, SP1 or SP2.
H
Sp
lo
H
MV
Sp
hi
W
i
a
i
A0046579
 3 SSC, Window
H Hysteresis
W Window
Sp
lo
Switch point with lower measured value
Sp
hi
Switch point with higher measured value
MV Measured value
i inactive (orange)
a active (green)
Two-point mode
SP
hi
always corresponds to whichever value is higher, SP1 or SP2 and SP
lo
always
corresponds to whichever value is lower value, SP1 or SP2.
Hysteresis is not used.
