Commissioning Deltabar PMD75B HART
40 Endress+Hauser
9.7.2 Commissioning with an operating menu
All configuration tools offer a Commissioning wizard that helps the user to configure
the most important configuration parameters (Guidance menu Commissioning
wizard).
Commissioning comprises the following steps:
• Position adjustment/zero adjustment
• Configuring measurement
Performing position adjustment/zero adjustment with the local display
Perform position adjustment/zero adjustment if necessary:
• In the main menu, select the Guidance menu Commissioning wizard with the or
key
Press the key
• Select the Zero adjustment parameter with the key
Press the key until you Zero adjustment parameter is reached
Press the key
• Select the Confirm option with the key
• Press the key
Position adjustment/zero adjustment has been performed.
Press the key until the end of the Wizard is reached and press the key to exit the
Wizard.
Back to the main menu: press the and key simultaneously (2 x).
Performing position adjustment/zero adjustment with FieldCare
Perform position adjustment/zero adjustment if necessary.
In the Zero adjustment parameter, select the Confirm option and press Enter.
In the Application menu, select the Sensor submenu Sensor calibration submenu Zero
adjustment parameter and press Enter.
Position adjustment/zero adjustment has been performed.
