50
Programming
To select the output table, proceed as described in 7.2.1. Select table in the
characteristic selection menu.
Function Selection Factory setting
See Current Output table
Selection of characteristic for Linear, bilinear, logarithmic, Linear
the output signal table
Table element selection Entry of number of value pairs 2
(elements): 2 to 21
Entry of values for current 0 to 100%
output (%) and conductivity 0 to upper measuring range
(µS/cm) value (depends on meas.
cell connected)
Press the E key when finished entering numeric values.
When programming is complete, the table values are checked. The current output and
conductivity values must increase from one table element to the next; if this is not the
case, this is indicated by an appropriate message:
Percent values not monotonously increasing
or Cd values not monotonously increasing.
7.2.2 Hold Type (Current Output During Hold)
Function Selection Factory setting
Selection of hold function type Fixed current value Fixed current
Last measured value value
Entry of fixed current value Current value during hold: 20.00 mA
(if fixed current value has been 0 to 22 mA
selected)
Note!
When set to last measured value, the corresponding value is stored in
EEPROM. When the instrument is restarted with the hold condition active, this
stored value is output.
