Endress+Hauser Proline Prosonic Flow 91 User Manual

Identification Proline Prosonic Flow 91
8 Endress+Hauser
2.1.2 Nameplate of the sensor
a0005874
Fig. 2: Nameplate specifications for the "Prosonic Flow W" sensors (example)
1 Ordering code/serial number: See the specifications on the order confirmation for the meanings of the
individual letters and digits.
2Sensor type
3 Nominal diameter
4 Fluid temperature range
5 Reserved for information on special products
6 Please comply with the Operating Instructions
7 Reserved for additional information on device version (approvals, certificates)
8 Degree of protection
9 Permitted ambient temperature range
2.1.3 Nameplate of the connections
a0005394
Fig. 3: Nameplate specifications for the transmitter (example)
68700 Cernay France
ENDRESS+HAUSER
TYPE 6P
NEMA
Tamb/Tumg:-20°…+60°C
Warning: To maintain
Type/NEMA XorIP
protection the connector
must be fully engaged.
IP68
CH 1
Prosonic Flow W
XXXXX-XXXXXXXXXXXX
W-CL-1F-M-B
12345678901 RY
0°C(+32°F)…+130°C(+266°F)
Order Code:
DN100 - DN4000
Type:
Ser.No.:
i
OPEN CLOSE
1
2
3
4
5
6
8
N12895
6
7
24
+
25
–
26
+
27
–
L1 (L+)
12
N (L–)
$
PULSE-OUT
fmax: 100 Hz
Passive: 30 VDC
250 mA
I-OUT (HART)
Active: 4...20 mA
RLmax. = 700 Ohm
HART
RLmin. = 250 Ohm
Supply /
Versorgung /
Tension
d’Alimentation
See operating manual
Betriebsanleitung beachten
Observer Manual d’Instruction
319740-0000
