Page #75 background imageLoading...
Page #75 background image
Proline Prosonic Flow 91 Description of device functions
Endress+Hauser 75
11.6 Group USER INTERFACE
Functional description USER INTERFACE
FORMAT Use this function to define the maximum number of places after the decimal point
displayed for the reading in the main line.
Options:
XXXXX.
XXXX.X
XXX.XX
XX.XXX
X.XXXX
Factory setting:
X.XXXX
!
Note!
Note that this setting only affects the reading as it appears on the display, it has no
influence on the accuracy of the system's calculations.
The places after the decimal point as computed by the measuring device cannot always
be displayed, depending on this setting and the engineering unit. In such instances an
arrow appears on the display between the measuring value and the engineering unit
(e.g. 1.2 l/h), indicating that the measuring system is computing with more decimal
places than can be shown on the display.
CONTRAST LCD Use this function to optimize display contrast to suit local operating conditions.
User input:
10 to 100%
Factory setting:
50%
TEST DISPLAY Use this function to test the operability of the local display and its pixels.
Options:
OFF
ON
Factory setting:
OFF
Test sequence:
1. Start the test by selecting ON.
2. All pixels of the main line and additional line are darkened for at least 0.75 seconds.
3. The main line and additional line show an "8" in each field for at least 0.75 seconds.
4. The main line and additional line show a "0" in each field for at least 0.75 seconds.
5. The main line and additional line show nothing (blank display) for at least
0.75 seconds.
When the test completes the local display returns to its initial state and the setting changes
to "OFF".
