Page #93 background imageLoading...
Page #93 background image
Proline Prosonic Flow 91 Description of device functions
Endress+Hauser 93
11.15 Group CONFIG. CHANNEL
Functional description CONFIG. CHANNEL
SENSOR TYPE Options:
W-CL-1F-L-B
W-CL-2F-L-B
W-CL-1F-L-C
W-CL-05F-L-B
W-CL-1F-M-B
W-CL-2F-M-B
Factory setting:
W-CL-2F-L-B
SENSOR
CONFIGURATION
Use this function to select the configuration for the ultrasonic clamp-on sensors.
Options:
NO. TRAVERSE: 1
NO. TRAVERSE: 2
NO. TRAVERSE: 4
Factory setting:
NO. TRAVERSE: 2
!
Note!
1 traverse for nominal diameters larger than DN 600, for certain plastic pipes with a
wall thickness greater than 4 mm or if the signal strength is not sufficient in other
arrangements.
2 traverses is the recommended configuration for pipes smaller than DN 600.
4 traverses can only be used for DN 50 in exceptional circumstances. The
recommended configuration is 1 traverse.
CABLE LENGTH Use this function to select the length of the sensor cable.
Options:
LENGTH 5 m/15 feet
LENGTH 10 m/30 feet
LENGTH 15 m/45 feet
LENGTH 30 m/90 feet
LENGTH 60 m/180 feet
LENGTH 100 m/300 feet
Factory setting:
LENGTH 5 m/15 feet
!
Note!
The influence on the flow measurement caused by the cable length is minimal with
nominal diameters under DN 80. For larger nominal diameters, the result is negligible.
