User’s Manual
V1.0
74
Specifications
VIDEO
Signal Format NTSC or PAL (Auto Detect)
Video Input Composite: 16 inputs, 1 Vp-p, auto-terminating, 75 Ohms
Monitor Outputs
Composite: 1 BNC, 1 Vp-p, 75 Ohms
VGA: 1
Video Resolution
Composite: 720x480 (NTSC), 720x576 (PAL)
VGA: 800x600, 1024x768, 1280x1024 @ 60Hz
Record Speed
(images per second)
Real-time: 480ips (NTSC), 400ips (PAL) @ CIF
Playback Speed
(images per second)
Full Duplex: 480ips (NTSC), 400ips (PAL) @ CIF
INPUTS/OUTPUTS
Alarm Input 16 terminal, programmable as NC or NO, 2.4V (NC) or 0.3V (NO) threshold, 5VDC
Alarm Output 1 relay output, 2A@125VAC, 1A@30VDC (NO)
Internal Buzzer 80dB at 10cm
Network Connectivity 10/100 Mbps Ethernet (RJ-45)
Text Input POS Interface, ATM Interface
CONNECTORS
Video Input Composite: 16 BNC
Monitor Output
Composite: 1 BNC
VGA: 1 VGA
Alarm Input/Output Terminal Blocks
Ethernet Port RJ-45
RS232 Serial Port Two-connector terminal block
RS485 Serial Port Two-connector terminal block
IR Port 1 Remote Control
USB Port 2 (USB 2.0)
STORAGE
Primary Storage SATA hard disk drive
Secondary Storage USB hard disk drive or flash drive
GENERAL
Dimensions (W x H x D)
11.8" x 2.4" x 9.1" (300mm x 62mm x 232mm)
Unit Weight 5.5 lbs. (2.5kg)
Shipping Weight 8.5 lbs. (3.85kg)
Shipping Dimensions
(W x H x D)
14.2" x 4.4" x 15.4" (360mm x 113mm x 390mm)
Operating Temperature 41°F to 104°F (5°C to 40°C)
Operating Humidity 0% to 90%
Power 12V , 1.9A (Adaptor: 100-240V~, 50/60Hz, 1.5A, 12V , 5A)
Power Consumption Max. 25W
Approvals FCC, CE
Specifications are subject to change without notice.
