The figure below shows the locations of the different output options available.
Up to three output options can be installed and operate simultaneously:
- 4-20mA ou 0-10V ( only one )
- RS232C ou RS485 ( only one)
- 2 RELAYS, 4 RELAYS ou 4 OPTOS ( only one ). Dimensions and mounting
Front: 96 x 48 mm Depth: 60 mm
Panel cut-out : 92 x 45 mm
CLEANING: frontal cover should be cleaned only with a soft cloth
soaked in neutral soap product.
DO NOT USE SOLVENTS
