13.5 Guideline and manufacturer’s declaration – electromagnetic immunity
The EN-Motion is intended for use in the electromagnetic environment specified below. The customer or the user of the EN-Motion
should assure that it is used in such an environment.
Immunity test
IEC 60601
test level
Compliance level
Electromagnetic environment
–
guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
 6 kV kV contact
 8 kV air
 6 kV kV contact
 8 kV air
Floors should be wood, concrete
or
ceramic tile. If floors are covered
with
synthetic material, the relative
humidity
should be at least 30 %.
Electrical fast
transient/burst
IEC 61000-4-4
 2 kV for power
supply lines
 1 kV for input/output
lines
 1 kV for power
supply lines
not applicable
Mains power quality should be
that of a
typical computer room.
Surge
IEC 61000-4-5
 1 kV line(s)to line(s)
 2 kV line(s)to earth
 1 kV line(s)to line(s)
 2 kV line(s)to earth
Mains power quality should be
that of a
typical computer room.
Voltage dips,short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
<5 %U T
(>95 %dip in U
T
)
for 0,5 cycle
40 %U T
(60 %dip in U T)
for 5 cycles
70 % U T
(30 %dip in U T)
for 25 cycles
<5 % U T
(>95 %dip in U T)
for 5 sec
< 5% U
T
for 0,5 cycle
< 5% U
T
for 1 cycle
70% U
T
for 25 cycles
< 5% U
T
for 5 sec.
Mains power quality should be
that of a typical computer room. If
the user of the EN-Motion
requires continued operation
during power mains interruptions,
it is recommended that the EN-
Motion be powered from an
uninterruptible power supply.
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m
3A / m
Power frequency magnetic fields
should be at levels characteristic
of a typical location in a typical
computer room.
NOTE U
T
is the a.c. mains voltage prior to application of the test level.
