Enterasys S-Series S8 Chassis Hardware Installation Guide 1-1
1
Introduction
ThischapterprovidesanoverviewoftheS8chassisanditsfeatures.
Overview
TheS8chassisdesignprovideseightslotsforSSeriesmodules.AllSSeriesmodulesinstalledin
theS8chassisoperateasasystemwithasingleIPaddress.
TheS8chassissupportsthefollowing:
•HotswappableSSeriesmodules
•LoadsharingI/Ofabricmodules
•Fieldreplaceablefantrays
•Redundantpowersupplies
IEEE
802.3afand802.3atPoweroverEthernet(PoE)
TheS8chassiscanbeinstalledasafreestandingunitorinstalledintoastandard48.26centimeter
(19inch)rack.
Allchassiscomponents(powersupplies,fantray,andmodules)areinstalledfromthefrontofthe
chassisforeaseofmaintenance.AllLEDindicators
areobservablefromthefrontofthechassisto
aidinmonitoringnetworkoperationalstatusandperformingmaintenance.
TheS8chassiscanbeinstalledbyitselforwithaPoEsubsystemtoprovidededicatedPoEpower.
TheS8chassissupportsboththefourbayPoEsubsystemandtheeightbayPoE
subsystem.
Figure 11showstheS8chassis(S8Chassis)withslotsforthreeI/Ofabricmodules,fiveI/O
modules,andfour
1200/1600wattredundantpowersupplies.Figure 12showstheS8chassis
equippedwiththefourbayPoEsubsystem(S8ChassisPOE 4).Figure 13showstheS8chassis
equippedwiththeeightbayPoEsubsystem(S8ChassisPOE8).
