Features
Enterasys S-Series S8 Chassis Hardware Installation Guide 1-5
Features
S-Series Modules
TheS8chassissupportsS‐SeriesS130andS150I/OfabricmodulesandI/Omodules,withsomeof
thesemodulesdesignedtobeexpandedwithoptionmodules.PortoptionsontheS‐Series
modulesare10/100/1000BASE‐TXRJ45ports,1000BASE‐XSFPports,and10GBASE‐XSFP+ports.
IEEE802.3afand
802.3atPoweroverEthernet(PoE)issupportedonthe10/100/1000BASE‐TXRJ45
ports.
TheS8chassis,whichhaseightslots,canacceptuptofiveI/OmodulesandthreeI/Ofabric
modules.
Redundant Power Supplies
TheS8chassissupportsfourS‐AC‐PSpowersuppliesthatresideinthelowersectionofthe
chassis,inslotslabeledPS1,PS2,PS3,andPS4.Thesecond,third,andfourthpowersupplies
provideloadsharingand,dependingonhowtheS8chassisispopulated,redundancy.
TheS‐AC‐PS
isa1200/1600wattpowersupply,whichhasonefront‐panelACinputpower
connector.Thetypeofpowercordshippedwiththeunitiscountry‐dependent.Eachpowercord
mustbepluggedintoanindependentpowercircuit.
TheS‐AC‐PSiscapableofloadsharingtheS8chassis
powerload.Ifapowersupplyfails,the
otherpowersuppliessupporttheentireloadofthechassiswithoutinterruptiontonetworktraffic.
Referto“SiteGuidelines”onpage 2‐1forpoweroutletrequirements.
Power Supply Status
TheS‐AC‐PSpowersuppliesreportinformationregardingtheirpresentoperatingstatus.This
informationincludesthefollowing:
•PowersupplyID(PS1,PS2,PS3,PS4)
•Powersupplystatus(normal/fault/notinstalled)
•Powersupplyredundancyindication(redundant/notavailable)
RefertotheEnterasysS‐SeriesCLIReferenceGuideforinstructionsonhowtoaccesspowersupply

statusinformationusingLocalManagement.
Auto-Ranging Power Supplies
TheS‐AC‐PSpowersuppliesautomaticallyadjusttotheinputvoltageandfrequency,which
allowsforaninputvoltageof100to220 Vac,andafrequencybetween50and60 Hz.Seethe
operatingspecificationsinAppendix A.Noadditionaladjustmentsarenecessary.Forinstallations
inNorthAmericaone20A
powercordisrequired.See“InstallingtheS‐AC‐PSPowerSupplies”
onpage 3‐16formoredetails.
Note: Each S-AC-PS power cord must be connected to an independent AC power source to
handle the input power requirements.
