Installing and Removing an S-DC-PS Power Supply
Enterasys S-Series S4 Chassis Hardware Installation Guide 3-19
Unpacking an S-DC-PS Power Supply
To unpack the S-DC-PS power supply:
1. Open the box and remove the packing material protecting the power supply.
2. Verify the contents of the carton as listed in Table 3-3.
3. Remove the tape seal on the non-conductive bag to remove the module.
4. Perform a visual inspection of the power supply and cable harness for any signs of physical
damage. Contact Enterasys Networks if there are any signs of damage. Refer to “Getting
Help” on page xvii for details.
Installing the S-DC-PS Power Supply
When you receive your S4 chassis, a coverplate will be in place over all power supply slots except
PS1. This slot is left open for your convenience when installing the first power supply.
You must install the power supplies in the slots labeled PS1, PS2, PS3, and PS4 at the bottom of the
chassis. If you intend to install a single power supply, you must install it in the power supply slot
labeled PS1.
A Phillips screwdriver is required to install the S-DC-PS power supply in an S4 chassis.
To install S-DC-PS power supplies in your S4 chassis:
1. Attach the ESD wrist strap shipped with your S4 chassis to your wrist and plug the cable from
the ESD wrist strap into the ESD grounding receptacle on your chassis.
2. Locate the PS1 power supply slot, as shown in Figure 1-2 on page 1-3.
3. Ensure that the breaker switch on the DC power supply is set to Off.
4. Hold the power supply by placing one hand on the handle located on the front panel and
using your other hand to support the power supply.
5. Holding the power supply with the terminal studs on the left and the handle on the right,
align with the slot opening.
Table 3-3 Contents of S-DC-PS Carton
Item Quantity
S-DC-PS power supply 1
Plastic bag containing 5 nuts, 5 lock washers, and two 2-hole compression lugs. 1
DC Power Supply Notice 1
Caution: To prevent equipment damage, do not install AC and DC power supplies in the same
chassis.
Precaución: Para evitar que el equipo se dañe, no utilice las fuentes de poder CC y CA en el
mismo chasis.
Notes: Before you power up the S4 chassis, you must complete installation of fan trays and
modules.
You must install the S-DC-PS power supply in the S4 chassis
before powering up the power supply.
If you power up the S-DC-PS power supply before installing it in the S4 chassis, the S4 chassis will
not properly recognize the power supply.
