Enterasys S8-Chassis-POE4 - Removing the Swing Arm from the Bottom Cable Management Clip; Closing a Cable Management Clip

Installing the S8 Chassis
3-10 Chassis Setup
2. Beforeinstallingthebottomcablemanagementclip,removeitsswingarm.SeeFigure 3‐6.
Figure 3-6 Removing the Swing Arm from the Bottom Cable Management Clip
3. Installthebottomcablemanagementclipontheleftmountingbracket.
4. Closeeachcablemanagementclipbysnappingitsswingarmintothecablemanagementclip
below.SeeFigure 3‐7.
Figure 3-7 Closing a Cable Management Clip
