Enterasys S8-Chassis-POE4 - Attaching the MID-Mount Brackets to the Front of the Chassis

Installing the S8 Chassis
Enterasys S-Series S8 Chassis Hardware Installation Guide 3-5
2. Attachthemid‐mountbracketstothefrontoftheS8chassiswiththetwelve10‐32panhead
screwssuppliedwiththemid‐mountbracketkit(sixscrewsforeachbracket).SeeFigure 3‐2.
Figure 3-2 Attaching the Mid-mount Brackets to the Front of the Chassis
Continueto“Mid‐MountinganS8Chassis”onpage 3‐8forthemid‐mounting
rackinstallation
procedure.
