Removing and Installing a Fan Tray
3-20 Chassis Setup
3. Slowlyslidethefantrayoutofitsslotinthechassis.SeeFigure 3‐14.
Figure 3-14 Removing the Fan Tray
Installing a Fan Tray
Toinstallafantray:
1. Attachtheanti‐staticwriststrapasdescribedin“AttachingtheElectrostaticDischargeWrist
Strap”onpage 3‐14beforehandlingthefantray.
2. Holdthehandleofthefantraywithonehandandthebottomofthefantraywiththeother
hand.
Youshould
holdthefansothattheSTATUSLEDlabelonthefaceplateisright‐sideup.
3. Lineupthetopandbottomofthefantraywiththeslotguidesonthechassis.
4. Slidethefantrayintothechassisuntilthefaceplateofthetrayisflushwiththeface
oftheS8
chassis.
Ifthereisanystrongresistance,removethefantrayand reinsertit.
5. TightenthetwocaptivescrewstosecurethefantraytotheS8chassis.
1 Captive screw (2) 2 Fan tray handle
Caution: In the following step, ensure that you do not force the fan assembly into place as it may
damage the self-aligning power/control connector in the chassis.
Precaución: En el siguiente paso, tenga cuidado de no colocar de manera forzada el sistema de
ventilación, porque puede dañar el conector de control de corriente con autoalineación del chasis.
