Unpacking the S8 Chassis
3-2 Chassis Setup
fantray.RefertoChapter 2,InstallationRequirementsandGuidelines,forinstallation
guidelines.
Unpacking the S8 Chassis
TheS8chassis,withorwithoutaPoEsubsystem,ispackedandshippedonaskid.Before
unpackingthechassis,examinetheoutsidepackagingforobviousdamage.
TounpacktheS8chassis:
1. Withaboxcutter,cutthetwoshippingstrapsfasteningthecorrugatedboxtotheskid.
2. Liftandremovethe
shippingboxfromtheskid.
3. Removeandsavetheaccessorypackage,documents,andcablefromthetopofthestyrofoam
cap.SeeTable 3‐1.
4. Liftandremovethestyrofoamcapfromthetopofthechassis.
5. Removetheboltsthatsecurethechassistotheskid.
6. Openthetopofthe
shippingbagcoveringtheunit,thenpullthebagdownaroundthe
chassis.
7. Liftandremovethechassisfromtheskid.
Saveallshippingmaterialsforfuturereshipping,ifnecessary.
8. Inspectthechassisforanysignsofphysicaldamage.
Ifthereareanysignsofdamage,DONOTinstallthechassis;instead,
contactEnterasys
Networks.Referto“GettingHelp”onpage xviifordetails.
Thefollowingperipheralsshipseparately:
•I/Omodules
•I/Ofabricmodules
•S‐AC‐PSpowersuppliesand20Ampline(inlet)cords(oneperpowersupply)
•S‐POE‐PSpowersupplies
•Mid‐mountbrackets(2)
Note: Unpack the S8 chassis components only as needed. Leave the components in their
respective shipping cartons until you are ready to install that component. Save all shipping
materials in the event that the chassis has to be repacked.
Table 3-1 Accessories That Ship with the S-Series Chassis
Item
Electrostatic Discharge (ESD) wrist strap
Installation documentation
Rubber feet
USB cable
RJ45 Console port cable
RJ45-to-DB9 adapter
Cable management clips
