Enterasys S8-Chassis-POE4 - Removing an S-POE-PS Power Supply; Removing Cover Plates from the Poe Subsystem Power Supply Slots

Installing and Removing an S-POE-PS Power Supply
Enterasys S-Series S8 Chassis Hardware Installation Guide 3-23
4. Ifyouare installingmorethanonepowersupply,removethecoverplatesfromtheapplicable
numberofpowersupply
slotsbyunscrewingthecaptivescrewthatattacheseachcoverplate
tothePoEsubsystem.SeeFigure 3‐16.
Figure 3-16 Removing Cover Plates from the PoE Subsystem Power Supply Slots
Keepthecoverplatesintheeventyouneedtoremovethepowersupplies.ThePoEsubsystem
shipswithoutacoveronbay1.
5. Repeatsteps1through3foreachadditionalpowersupply.
Removing an S-POE-PS Power Supply
ToremoveanS‐POE‐PSpowersupply:
1. Attachtheanti‐staticwriststrapasdescribedin“AttachingtheElectrostaticDischargeWrist
Strap”onpage 3‐14beforehandlingthepowersupply.
2. UnplugthepowercordfromthededicatedACoutlet.
3. UnplugthepowercordfromtheACpowerconnectorofthe
appropriatepowersupply.
4. Releasethespringcliponthelowerleftofthepowersupply’sfaceplatetounlocktheejection
handle.
5. Graspingtheejectionhandle,slidethepowersupplyoutofthePoEsubsystem.
