Installing and Removing an S-POE-PS Power Supply
Enterasys S-Series S8 Chassis Hardware Installation Guide 3-21
Installing and Removing an S-POE-PS Power Supply
IfyourS8chassisisequippedwithaPoEsubsystem,youmustinstallS‐POE‐PSpowersuppliesto
providePoEpowertothepowereddevices(PDs)attachedtothe10/100/1000MbpsRJ45portsin
theinstalledS‐SeriesI/Omodules.
Unpacking the S-POE-PS Power Supplies
TheS‐POE‐PSpowersupplymodulesareshippedinboxesseparatefromtheS‐Serieschassis.To
unpackapowersupply:
1. Unpackthepowersupplybyremovingitfromtheshippingboxandslidingthetwofoamend
capsofftheunit.
Savetheshippingboxandmaterialsinthe
eventtheunitmustbereshipped.
2. VerifythecontentsoftheboxusingTable 3‐3asappropriate.
3. Removethepowersupplyfromitsprotectiveplasticbag.
4. Examinethepowersupplycarefully,checkingfordamage.
Ifthereareanysignsofdamage,DONOTinstallthepowersupply;instead,contactEnterasys
Networks.Refer
to“GettingHelp”onpage xviifordetails.
Note: You must order S-POE-PS power supplies separately.
Table 3-3 Contents of S-POE-PS Power Supply Carton
Item Quantity
S-POE-PS power supply 1
For USA shipments: NEMA Power Cord 6-20, C19, R/A, SHLD
Type of power cord is dependent on country of installation.
1
NOTICE Card 1
