Enterasys S8-Chassis-POE4 - Removing an S-AC-PS Power Supply; Removing a Coverplate from an S-AC-PS Power Supply Slot

Installing and Removing an S-AC-PS Power Supply
3-18 Chassis Setup
6. Ifyouare installingmorethanonepowersupply,removethecoverplatesfromtheapplicable
numberofpowersupply
slots,asshowninFigure 3‐13.
Keepthecoverplatesintheeventyouneedtoremovethepowersupplies.
Figure 3-13 Removing a Coverplate from an S-AC-PS Power Supply Slot
7. Repeatsteps2– 5foreachpowersupply.
Aftercompletingthepowersupplyinstallations,theS8chassisisreadytobepoweredup.
ProceedtoPoweringuptheS8Chassisforinstructionsto
powerupthechassis.
Removing an S-AC-PS Power Supply
Wheneverpossible,youshouldinstallareplacementpowersupplybeforeremovingapower
supply.
ToremoveanS‐AC‐PS powersupply:
1. Attachtheanti‐staticwriststrapasdescribedin“AttachingtheElectrostaticDischargeWrist
Strap”onpage 3‐14beforehandlingthepowersupply.
2. Unplugthepowercordfromthe
dedicatedACoutlet.
3. UnplugthepowercordfromtheACpowerconnectorofthepowersupply.
4. Unscrewthecaptivescrewstoreleasethepowersupplyfromthechassis.
5. Graspthepowersupplyhandleandpullthepowersupplystraightoutofthechassis.
1 Power supply slot 3 Captive screw
2 Coverplate
