10 +5 V REF
• This is an internally regulated and monitored reference voltage supply for external devices.
• This reference output can be switched on/off by application.
10.1 Protection features
• Overcurrent
• External voltage protection
• Errors are indicated with a fault signal
10.2 Voltage monitoring
The level of the output voltage can be monitored by application.
Electrical characteristics
Symbol
Parameter
Conditions
Min
Max
Units
V
o-level
Output voltage
Output On; Unconnected
pins
typ. 5 V
R
o
Output Resistance
Output On
2
Ω
I
o
Nominal Output Current
Output On;
0
100
mA
I
o-lim
Internal Current
Limitation
Output On (Note 2, 3) typ. 500
mA
I
o-sc
Short-circuit Current
Limit
Output On; Overcurrent, R
L
=
0
typ. 350
mA
C
o
Output Capacitance
typ. 47
uF
Fault-signal overvoltage
threshold level
External overvoltage
conditions
typ. 5,7
V
V
I-max
Max Input voltage Overload conditions (Note 1) 0 36 V
Voltage monitoring
V
I
Nominal Voltage
measuring range
0 7 V
Scaling Factor
(Note 4)
typ. 0,5
V/V
Note 1: When output voltage is under overload conditions, for example, short circuit to supply
voltages. Exceeding the max value might cause damage to output.
Note 2: Current limit for overcurrent protection to limit internal power dissipation.
Note 3: When the limit is exceeded, the output current is regulated. In regulation, the output is
switched into overcurrent mode.
Note 4: The measurement is scaled down before the conversion. The effect is compensated in
Epec software libraries. For more information, see Epec Programming and Libraries manual.
