12.6 GSM/UMTS (GPRS/3G/HSPA+/Modem)
This manual describes the full hardware version. Some of the features are
optional and not implemented in all hardware versions.
Make sure SIM card slot is properly closed to ensure tightness protection.
SIM slot cover is tightened with two Torx TX6 M2x4 (DIN 965) screws.
Switch off
system power when changing the SIM card.
Firewall can be activated for the modem, for more information refer to Epec
Programming and Libraries Manual.
SMA connector in the unit:
RP-SMA female
SMA connector type for antenna:
RP-SMA male *
SMA tightening torque:
brass: 0,3 - 0,6 Nm
steel: 0,8 - 1,1 Nm
Supported frequencies:
Global coverage:
• 800/850/900/1900/
2100MHz@UMTS
•
850/900/1800/1900MHz@GSM
SIM card size:
Mini-SIM (2FF)
SIM requirements:
Switch off the PIN code request
SIM card slot type:
Push-push
Ordering antenna:
See section Accessories and Ordering
Codes *
Related programming libraries:
Modem.library
(For more information, see Epec
Programming and Libraries manual)
*) Tested with Plantec Planar Combination Antenna K70ZVR (for using other antenna types,
additional testing is required)
