13 INTERNAL DIAGNOSTICS
13.1 Temperature and Voltage Monitoring
13.1.1 Temperature Monitoring
This unit has an internal temperature sensor for monitoring the unit's internal temperature.
The temperature information is useful for self-diagnostic purposes and safety features.
PCB Area Temperature
Symbol
P
arameter
Conditions
Min Max Unit
T
PCB
Nominal PCB Temperature
measuring range
-55 +125 °C
T
PCB-err
Temperature Measurement
Error
-40 .. +100 °C +/- 6
% (FS)
-55.. +125 °C +/- 9 % (FS)
Diagnostics
Low High Unit
Recommended warning
levels
-30 +80 °C
Processor Core Temperature
Symbol
Parameter
Conditions
Min Max Unit
T
Core
Nominal Core Temperature
measuring range
-40 +125 °C
Diagnostics
Low High Unit
Recommended warning
levels
-30 +80 °C
Screen dimming Non-configurable +90 °C
Lowering CPU clock
frequency to half
Non-configurable +95 °C
Shut-down Non-configurable +100 °C
