7 DO/DI
Possible pin modes:
Sourcing DO mode (pull-up)
Sourcing DO mode (pull-down)
DI mode (pull-up)
DI mode (pull-down)
7.1 DO (digital output) mode
This pin type is a current sourcing output with a pull-up selection
The pin connects the load to a positive supply voltage
This pull-up feature is for open load detection when the pin is used as an output
These outputs have a switching element called a smart FET. It has integrated features to
protect itself and also the external pin, wiring and actuator.
When used as an output, the input feature indicates the output FET's state
It is recommended to use the function blocks in DigitalOutputDiagnostics library to
protect and diagnose outputs when used as digital outputs. For more information,
refer to Epec Programming and Libraries Manual.
7.2 DI (digital input) mode
This pin can be used as a digital input (DI) by using the output state monitoring feature
In this case, the output (DO) functionality of the pin type must be kept OFF
This pin can be used also with NPN-type sensors sensors with open collector/open drain
It’s highly recommended to use closed loop connections when the output pin is used as an
input. By keeping this simple principle in your mind you will avoid many unknown problems
later on
Electrical characteristics
Symbol
Parameter
Conditions
Min
Max
Units
V
Level
Output voltage
Output Off, Pull-up
selected, Unconnected
pin,
U
in
= 24 V
V
Level
= U
in
/1,3
typ. 18,5 V
I
o
Nominal Output Current
Output On
(Note 3, 4)
0 1 A
I
o-lim
Internal current limitation Output On (Note 2, 6) typ. 12 A
Digital status input
R
I
Input Resistance
Output Off, Pull-
up resistor
not selected, V
I
< U
in
(referenced to GND)
typ. 44
Output Off, Pull-
up resistor
selected, (referenced to
U
in /1,3)
typ. 8,1
