EPSON Stylus PHOTO 2100/2200 Revision B
MAINTENANCE Overview 215
6.1 Overview
This section provides information to maintain the printer in its optimum condition.
6.1.1 ROM Replacement
This printer may require the ROM to be replaced when program changes or additions
are made. In such cases, use the special tool (ROM puller: 2035659 (#F749)) to replace
the ROM. The position of the ROM is shown in the figure below.
Figure 6-1. ROM Location
When installing the ROM into the socket, fit the glossy "#"-marked edges on the
four corners of the ROM into the notches of the socket.
6.1.2 Cleaning
This printer has no mechanical components which require regular cleaning except the
printhead. Therefore, when returning the printer to the user, check the following parts
and perform appropriate cleaning if stain is noticeable.
! Housing
Use a clean soft cloth moistened with water and wipe off any dirt. If the Housings
are stained with ink, use a cloth moistened with neutral detergent to wipe it off.
! Inside the printer
Use a vacuum cleaner to remove any paper dust.
ROM
C387 MAIN Board
C A U T I O N
" Never use chemical solvents, such as thinner, benzine, and
acetone to clean the exterior parts of the printer like the housing.
These chemicals may deform the components of the printer or
deteriorate the quality of the printer.
" Be careful not to damage any components when you clean inside
the printer.
" Do not scratch the surface of the PF roller assembly. Use a soft
brush to wipe off dust.
" Use a soft cloth moistened with dilute alcohol to remove ink
stain.
" Do not use the supplied cleaning sheet for normal usage. It may
damage the coated surface of the PF roller.
" If the adhesive surface of the cleaning sheet is set to the ASF LD
roller side and used to clean the ASF LD roller surface, it is no
problem.
