EPSON Stylus PHOTO 2100/2200 Revision B
ADJUSTMENT Adjustment Items and Overview 193
5.1.2 Priority of Adjustment Items
The items on the upper level should be adjusted earlier. The items in the horizontal direction have the same priority.
Figure 5-1. Priority of Adjustment Items
Main board data
read/write
Initial value write
PG adjustment
Initial charge sequence
Head ID input
Head angular adjustment
Bi-D adjustment
Pixel shift
CR motor drive torque
dispersion measurement
A3+ pattern printing
CR tooth skip prevention
mechanism adjustment
USB ID input
IEEE-1394 ID input
Waste ink counter reset
PF adjustment PW sensor adjustment
