Epson EB-E10 Service Manual

EB-E01 series Product Description INTERNAL USE ONLY
SEIKO EPSON 16 Revision A
Power
consum
ption
100-120V Area
(JAPAN, USA,
etc.)
Lamp
ON (Normal) 345W
ON (Medium) — — 303W 303W 303W 303W 303W
ON (Eco) 235W
Standby (Network On) 2.0W
Energy Saving 0.3W
220-240V Area
(Europe, etc.)
Lamp
ON (Normal) 327W
ON (Medium) — — 290W 290W 290W 290W 290W
ON (Eco) 225
Standby (Network On) 2.0W
Energy Saving 0.3W
Rated Voltage & Current (Except Japan) 100 - 240 V AC 50/60 Hz 3.5A - 1.6A
Size
Excluding feet
Unit: mm
302(W) x 87 (H) x
249 (D)
302(W) x 87 (H) x
249 (D)
302(W) x 87 (H) x
249 (D)
309 (W) x 90 (H) x
282 (D)
309 (W) x 90 (H) x
282 (D)
302 (W) x 87 (H) x
249 (D)
302(W) x 87 (H) x
249 (D)
Maximum Dimension
302(W) x 92 (H) x
249 (D)
302(W) x 92 (H) x
249 (D)
302(W) x 92 (H) x
249 (D)
309 (W) x 105 (H)
x 293 (D)
309 (W) x 105 (H)
x 293 (D)
302 (W) x 92 (H) x
260 (D)
302(W) x 92 (H) x
260 (D)
Weight
Approx. 5.95 lbs./
2.7 kg
Approx. 5.95 lbs./
2.7 kg
Approx. 5.95 lbs./
2.7 kg
Approx. 6.83 lbs./
3.1 kg
Approx. 6.83 lbs./
3.1 kg
Approx. 6.17 lbs./
2.8 kg
Approx. 6.17 lbs./
2.8 kg
Fan
noise
Normal mode 37 dB
Eco mode 28 dB
Model
EB-E20 EB-X49 EB-W49 EB-972 EB-982W EB-118 PL 119W
Item

Epson EB-E10 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	0 - 1.76 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	15000:1
Screen size compatibility	22 - 350 \
Projection distance (wide)	0.87 - 10.34 m
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-30 - 30 °
Projector brightness (economic mode)	2200 ANSI lumens
Lamp type	UHE
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Focus	Manual
Throw ratio	1.44 - 1.95:1
Fixed focal length	16.7 mm
Full HD	No
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
AC (power) in	Yes
Composite video in	0
HDMI connector type	Full-size
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
RMS rated power	2 W
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Housing material	Plastic
Market positioning	Presentation
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Bundled software	Inhalt DIY-App, Epson Projektor Management, Epson Projektor Professional Tool
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
USB display function	2 in 1: Image / Mouse

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2400 g
Package depth	376 mm
Package width	327 mm
Package height	152 mm
Package weight	3716 g
