EB-E01 series Product Description INTERNAL USE ONLY
SEIKO EPSON 17 Revision A
EB-FH06/FH52/992F, EH-TW740/TW750
Model
EB-FH06 EB-FH52 EB-992F EH-TW740 EH-TW750
Item
Specific
ation
of main
part
LCD
Size 0.61 inch (C2fine)
Pixel number 2,073,600 pixels (1920 x 1080) x 3
Native resolution Full HD
Aspect ratio 16:9
Projection Lens
Focus Type Manual
Zoom
Type Manual Manual Manual Digital Manual
Ratio 1-1.2 1-1.6 1-1.6 1-1.35 1-1.2
Lamp
Type UHE
Power consumption 210W 230W 230W 210W 210W
Life
Normal 6,000 hours 5,500 hours 6,500 hours 6,000 hours 6,000 hours
Medium 10,000 hours
Eco 12,000 hours 12,000 hours 17,000 hours 12,000 hours 12,000 hours
Brightn
ess
Normal mode
Color mode: Dynamic,
Zoom: Wide
3,500lm 4,000lm 4,000lm 3,300lm 3,400lm
Medium mode 3,400lm
Eco mode 2,300lm 2,400lm 2,400lm 2,200lm 2,200lm
Sound output Monaural: 2W x 1
Monaural: 16W x 1 Monaural: 16W x 1
Monaural: 2W x 1 Monaural: 2W x 1
I/O
Video input
Analog
D-sub 15pin 1 (Blue molding) 1 (Blue molding) 2 (Blue molding) 1 (Blue molding)
RCA 1 (Yellow) 1 (Yellow) 1 (Yellow) 1 (Yellow)
DigitalHDMI2 2212
Video output Analog D-sub 15pin 1
Audio
Input
RCA (L/R)1111
Stereo mini 2
Output Stereo mini 1 1 1
Mic Input Stereo mini 1
